Chapter 51: RFID's Read/Write Capability vs. Barcodes |
Executive Summary |
This chapter explores the fundamental distinction between barcodes and Radio Frequency Identification (RFID) technology: the read-only nature of barcodes versus the read/write capability of many RFID tags. While barcodes have served as the backbone of automatic identification for decades, their static, unchangeable data limits their utility in applications requiring dynamic information updates. RFID tags, particularly those with read/write memory, enable data to be written, updated, and stored directly on the tag throughout an item's lifecycle. This capability proves invaluable in cold chain logistics, pharmaceutical tracking, and numerous other industries where historical data---such as temperature exposure, repair records, or chain of custody---must accompany the physical item rather than reside solely in a remote database. |
The chapter examines these differences through practical industry applications, while also considering the enduring role of the Code 39 barcode symbology. Despite being one of the earliest barcode standards, Code 39 remains widely used due to its simplicity, alphanumeric support, and self-checking properties, though its low data density presents limitations that influence where and how it is deployed across various sectors. |
|
1. Introduction: The Static and the Dynamic |
The history of automatic identification is essentially a story of increasing intelligence. The first barcodes, such as the ubiquitous UPC symbol, were nothing more than a license plate---a simple, unique identifier that, when scanned, told a computer to look up a corresponding record in a database. This model, known as the 'read-only' paradigm, has proven extraordinarily successful. It is inexpensive, reliable, and universally supported. |
However, the world is not static. Products move through complex supply chains, change hands, are exposed to different environments, and accumulate history. A simple serial number, while useful for identification, cannot tell you if a vaccine was exposed to excessive heat, if a critical aircraft component was properly maintained, or if a high-value asset has been stolen. This is where the read/write capability of RFID represents a genuine paradigm shift. |
Unlike barcodes, which are immutable once printed, many RFID tags are equipped with rewritable memory. This allows data to be written to the tag at one point in its journey and read or updated at subsequent points. The tag becomes a dynamic, portable database that physically accompanies the item. This capability is not just a technical curiosity; it is a transformative enabler for modern logistics, healthcare, and manufacturing. |
|
2. The Core Distinction: Read-Only vs. Read/Write |
2.1. Barcodes: The Perpetually Read-Only Medium |
A barcode, whether a traditional one-dimensional (1D) linear symbol like Code 39 or a two-dimensional (2D) matrix like a QR Code, is a visual representation of data. The information is encoded in the pattern of bars and spaces (or modules). Once the label is printed, the data is fixed. It cannot be altered. If a product's status changes, if an expiration date passes, or if an inspection is completed, the barcode itself remains unchanged. |
This characteristic is both a strength and a limitation. The strength lies in its simplicity and permanence. It is an excellent way to apply a universally readable identifier to an item. The limitation is that the barcode carries no history and no context beyond its static identifier. Any additional information must reside in a database that the barcode points to. In essence, the barcode is a key to a door; it is not the contents of the room . |
2.2. RFID Tags: A Spectrum of Programmability |
RFID technology is far more varied. Tags can be broadly categorized based on their power source---passive, semi-passive (battery-assisted), and active---and their memory capabilities . While some RFID tags are designed to be read-only, functioning much like a barcode but with radio frequency interrogation, many offer read/write functionality. |
A read/write RFID tag contains a microchip with non-volatile memory. This memory can be divided into banks. Some banks might be permanently locked with a unique, unchangeable serial number (the tag's 'identity'), while other banks are left available for users to read, write, lock, or permanently lock data as needed . This allows the tag to be encoded with dynamic information throughout its lifecycle. |
For example, a manufacturer might write a serial number and production date to a tag. A logistics provider might then add a timestamp and GPS coordinates when the item leaves a warehouse. A retailer could then write a 'sold' timestamp and store location. This creates a portable, item-level history that does not rely on continuous network connectivity to be retrieved. |
2.3. The Database Dependency Dilemma |
The read-only nature of barcodes and some RFID tags creates a strong dependency on central databases. Every scan requires a network lookup to retrieve the relevant item information. As the AIM Global white paper on read/write RFID notes, this is a significant bottleneck . |
In a high-speed, unattended processing environment, an RFID system might boast a read rate of several dozen tags per second. However, if every read requires a query to a central database, performance is immediately throttled by network latency and database speed . In complex, multi-company supply chains, the database dependency becomes even more problematic. Questions arise about who owns the database, where it resides, who is responsible for maintenance, and how security and access are managed. While the Internet has been proposed as a universal medium for exchanging tag data, its ability to process millions of real-time reads with the speed of an RFID interrogation remains a significant challenge . |
Read/write tags circumvent this by storing critical information locally on the tag itself. An item can be processed based on the data written to its tag without requiring a network connection or a database lookup. This enables faster processing, reduces data latency, and provides resilience in environments where network connectivity is unreliable . |
2.4. Flexibility and Future-Proofing |
The ability to rewrite data also provides a level of future-proofing that is impossible with printed barcodes. The AIM Global report offers a compelling example: imagine a retailer mandates that suppliers identify pallets with a 10-digit serial number. A year later, the retailer changes its requirement to a 12-digit alphanumeric string. Suppliers using read/write RFID tags could simply rewrite the new information to their existing tags, incurring minimal cost and disruption. Those using read-only tags would be forced to purchase new tags for every pallet, remove the old ones, and apply the new ones---a costly and labor-intensive endeavor . |
This flexibility allows organizations to adapt to changing standards, customer requirements, or internal needs without abandoning their hardware investment. Tags can also be erased and completely reused. When a tracked item reaches the end of its useful life, the tag can be removed, erased, and reapplied to a new item. This reduces the total cost of ownership and makes RFID a more sustainable option . |
|
3. Industry Applications of Read/Write RFID |
The read/write capability of RFID is not an abstract advantage; it is the driving force behind adoption in several critical industries. |
3.1. Cold Chain and Pharmaceutical Logistics |
This is arguably the most impactful application of read/write RFID capabilities. The cold chain---the temperature-controlled supply chain for perishable goods, vaccines, and biologics---is a domain where historical data is paramount. Knowing the current temperature of a product is useful, but knowing its *complete temperature history* is essential to prove its efficacy and safety. |
The Static Problem with Barcodes: A barcode on a vaccine vial can identify the product, lot number, and expiration date. However, it cannot tell you if the vaccine was ever exposed to temperatures outside its safe range during transit. That information, if collected at all, would be stored in a separate logger or a database, creating a disconnect between the physical product and its data history. |
The Dynamic Solution with RFID: Semi-passive RFID tags, which have an onboard battery to power a sensor and memory while using backscatter to communicate, are frequently deployed for this purpose . These 'sensor tags' can be integrated with temperature sensors . As the product travels, the tag continuously logs temperature data. At each checkpoint, a reader can interrogate the tag and retrieve not just the product ID but also the entire temperature log, timestamped and verified . This data can also be written directly to the tag. |
Real-World Example: Mira Care Inventory Cabinet: A stark illustration of the value of dynamic data in cold chain management comes from the healthcare sector. In a well-documented 2024 incident, Canada's national emergency medicine stockpile lost approximately $20 million worth of medication simply because a freezer door was left partially open, causing temperature fluctuations that compromised the entire inventory . This high-profile failure highlights the vulnerability of static identification and manual monitoring. |
In response, companies like Intelliguard and Accucold have collaborated to create integrated RFID-enabled refrigerated cabinets. The Mira Care cabinet automates item-level tracking of refrigerated pharmaceuticals while simultaneously capturing real-time data on temperature, inventory movement, user access, and expiration status . The RFID tag on each medication vial is not just a static identifier; it is a data node that allows the system to continuously monitor and record conditions, enabling instant visibility into the storage environment and providing early warnings of potential problems. This is the power of a read/write ecosystem where the tag is a living data record. |
|
3.2. Manufacturing and Asset Tracking |
In manufacturing, the ability to write data to a tag directly on the production line is invaluable for quality control and process optimization. As an item moves through an assembly line, the RFID tag can be updated with data at each station. |
Repair and Maintenance Records: Consider a high-value asset like a jet engine turbine blade or a heavy-duty industrial pump. A barcode on the asset can tell you its serial number, which you can use to look up its maintenance history in a database. However, if a maintenance technician is working in a remote location without network access, they have no immediate access to that history. A read/write RFID tag can store the complete maintenance and repair record directly on the asset. A technician with a handheld RFID reader can immediately see when the part was last inspected, what repairs were performed, and by whom . This creates a tamper-proof, portable record of the asset's history, improving safety and reducing downtime. |
Work-in-Process (WIP) Tracking: Read/write RFID is also transforming WIP tracking. In complex assembly environments, tags on a carrier or workpiece can be used as a traveling work order. At each station, the tag can be read to display assembly instructions. Once the task is completed, the operator can write the completion time, quality control results, and their operator ID directly back to the tag. This creates a granular, real-time record of the manufacturing process. |
|
3.3. Healthcare and Patient Identification |
Beyond the cold chain, RFID's read/write capabilities are improving patient safety and workflow efficiency in hospitals. While barcoded wristbands are still common for patient identification, they are read-only. An NFC-enabled wristband can serve as a dynamic patient record . |
In an emergency, a first responder can scan a patient's NFC wristband to retrieve critical medical information such as allergies, blood type, and current medications. As the patient moves through the hospital, healthcare providers can write updates to the tag, noting treatments administered, test results, and vital sign thresholds . This ensures that the most up-to-date patient information is always physically with the patient, reducing the risk of medical errors and improving the speed of care . The tag is no longer just an identifier; it is a portable electronic health record. |
|
3.4. Retail and Inventory Management |
The retail sector has been one of the most aggressive adopters of RFID, primarily for inventory accuracy. While barcodes have long been the standard for point-of-sale (POS) checkout, they have proven inadequate for the high-speed, bulk inventory counts required in modern omnichannel retail . |
A barcode requires a direct line of sight and must be scanned one item at a time. An RFID reader, on the other hand, can read hundreds of tags per second without line of sight. This allows retailers to perform a complete store inventory in a fraction of the time it takes to scan barcodes, with reported accuracy rates exceeding 95%---a significant improvement over manual barcode scanning . |
The read/write capability adds another layer of sophistication. For example, in apparel retail, a garment with a read/write RFID tag can be tracked from the distribution center to the store floor and then to the fitting room. If the garment is tried on and not purchased, the tag could be updated to indicate it needs to be returned to the rack. More importantly, if the retailer wants to change the pricing information on thousands of items, this data can be written to the tags in bulk from a central system, eliminating the need for manual price tag replacement. |
|
3.5. Cross-Docking and Logistics |
Cross-docking is a logistics strategy where incoming shipments are directly sorted and transferred to outbound vehicles with minimal or no storage in between. The efficiency of this process depends on speed. Read/write RFID is particularly valuable here. |
A pallet arriving at a cross-dock facility with a read/write RFID tag can already contain its entire shipping manifest and Advance Ship Notice (ASN) data written to the tag . When the reader at the dock door scans the pallet, it retrieves the ASN information directly from the tag, not from a database. This allows the facility to immediately verify the shipment and sort it to the correct outbound door without waiting for a network lookup. This ability to process items based on locally stored data reduces bottlenecks and accelerates the flow of goods through the distribution network . |
|
4. The Enduring Role of Code 39 in an Evolving Landscape |
While the industry pushes toward dynamic, data-rich identification, the humble 1D barcode remains a fixture, and few symbologies are as iconic or widely deployed as Code 39. |
4.1. Technical Characteristics of Code 39 |
Developed by Intermec in 1974, Code 39 was the first barcode symbology to support both letters and numbers, a crucial feature for industrial applications . It is a discrete, variable-length barcode that encodes an alphanumeric character set including digits 0-9, uppercase letters A-Z, and several special characters . |
Key technical features include : |
1. No Check Digit Required: Unlike more modern symbologies like Code 128, Code 39 does not have a mandatory check digit. This simplifies printing and scanning. However, this is also a weakness, as it reduces error detection capability compared to symbologies that include a check digit. |
2. Self-Checking: Code 39 is considered self-checking because each character is encoded with exactly two wide bars and one wide space (out of nine total elements). If a printer error causes a narrow bar to become wide or vice versa, the error is likely to create an invalid character, preventing a misread . |
3. Low Data Density: This is the most significant drawback. Because Code 39 encodes each character with a pattern of nine elements, it requires considerably more horizontal space to encode the same amount of data compared to Code 93 or Code 128 . This makes it unsuitable for labeling very small items or encoding large amounts of data. |
4. Supported by Almost Every Reader: Due to its long history and simplicity, Code 39 can be decoded by virtually any barcode scanner on the market . This universality is a major driver of its continued use. |
|
4.2. Code 39 in the Automotive Industry |
The automotive industry is one of the primary bastions of Code 39. The US Department of Defense (DoD) and automotive manufacturers have long relied on Code 39 for parts labeling and tracking . A car is assembled from thousands of components, many of which must be tracked for quality control and recalls. |
A Code 39 label on an engine block, stamped with a VIN (Vehicle Identification Number) or a part number, provides a reliable, human-readable and machine-readable identifier. Its simplicity and robustness make it a good fit for the harsh factory environment. However, its low data density means that a long part number might require a very long label. In space-constrained areas, this is a distinct disadvantage, which is why the industry has also adopted other symbologies and is moving toward 2D codes. |
|
4.3. Code 39 in the Manufacturing and Defense Sectors |
Beyond automotive, Code 39 is widely used in general manufacturing for asset tracking, labeling, and work-in-process tracking . Its alphanumeric capability is a major advantage over early numeric-only barcodes. A manufacturer can encode a part number that includes both letters and numbers directly into the symbol without the need for a lookup table. It also meets the stringent labeling requirements of the US Department of Defense (DoD), which mandates specific identification standards for its suppliers . |
Strengths in this Context: The self-checking nature of Code 39 provides a degree of resilience in less-than-perfect printing environments. The fact that it is supported by a wide range of ruggedized industrial scanners makes it a safe, proven choice. For tracking large assets like pallets, cases, and heavy equipment, the low data density is less of a concern, as there is ample label space. |
|
4.4. Code 39 in Healthcare |
Although the healthcare industry is moving toward 2D Data Matrix codes for strict UDI (Unique Device Identification) compliance, Code 39 has historical significance in this sector. It has been used by the Health Industry Business Communications Council (HIBCC) for labeling medical devices and supplies . HIBCC's standard, the Health Industry Number (HIN) system, has historically leveraged Code 39 to encode supplier and product information. |
Again, the ease of adoption and the widespread availability of scanners made Code 39 a logical early choice. However, the low data density and lack of a check digit make it less suitable for the high-stakes environment of medical device tracking, where the ability to encode a serial number, lot number, and expiration date in a compact, highly reliable format is critical for patient safety. |
|
4.5. The Legacy and the Future |
Code 39's future is a story of coexistence, not extinction. It will continue to be used in its core, non-retail niches where simplicity and reliability are more valued than data density . However, the technological landscape is shifting. |
The GS1 Sunrise 2027 initiative, which mandates that all retail point-of-sale systems must be capable of scanning 2D barcodes like QR Codes and Data Matrix, is a significant push toward more data-rich identification . The industry is moving toward a future where a single smart label contains an RFID inlay for automated, bulk reading and a printed 2D barcode for manual verification and checkout . In this future, legacy symbologies like Code 39 will be relegated to specific, legacy use cases, but they will not disappear. |
|
5. The Convergence Model |
As the previous discussions show, the question is no longer 'barcode or RFID' but rather 'how can we use both effectively' Leading organizations treat barcodes and RFID as complementary layers of a unified identification infrastructure . |
The Hybrid Approach: In a modern supply chain, a product may have multiple layers of identification. At the item level, a barcode (EAN-13 for retail, Data Matrix for healthcare) enables POS checkout and consumer scanning. At the item level for high-value goods like apparel or electronics, an RFID tag provides a serialized identifier (SGTIN-96) for inventory control. At the case level, a barcode (GS1-128) and/or an RFID tag is used for receiving and picking. At the pallet level, an RFID tag with an SSCC (Serial Shipping Container Code) is read at dock doors for automated receiving. The RFID tag and the barcode on a smart label carry the same underlying GS1 identifier, ensuring data consistency . |
Digital Product Passports (DPPs): The read/write capability of RFID is a foundational technology for the emerging concept of Digital Product Passports. DPPs are a record of a product's lifecycle---from material sourcing to production, use, and end-of-life. They require a data carrier that can store and update large amounts of information as the product moves through its lifecycle. Read/write RFID tags, with their ability to be updated, are a perfect enabler for DPPs in a way that a static, printed barcode cannot match . |
|
6. Conclusion |
The comparison between the read-only nature of barcodes and the read/write capability of RFID is a testament to the evolution of data capture technology. Barcodes, including the resilient and widely deployed Code 39, represent the foundation of modern automatic identification. They are simple, cost-effective, and universally supported. However, their static nature makes them nothing more than 'license plates' that point to data in external databases. |
Read/write RFID tags, on the other hand, are the next step in this evolution. They transform an identifier into a dynamic, portable data record. This capability is not a luxury; it is a necessity in modern applications where history and context are as important as identity. In the cold chain, RFID tags carrying temperature logs provide the assurance that a critical vaccine or perishable food has been maintained within safe limits throughout its journey. In healthcare, they enable patient safety and improve workflow by keeping crucial medical information with the patient. In manufacturing, they create tamper-proof, portable repair and maintenance records, ensuring safety and compliance. In logistics, they reduce dependency on fallible networks and enable the high-speed, unattended processing required for operations like cross-docking. |
The future of automatic identification is not a war between barcodes and RFID. It is a convergence. The industry is moving toward a world where items are identified and tracked using a layered approach. A barcode, maybe a 2D code, will provide a universally accessible identifier and serve as a fallback. An RFID tag, with its read/write memory, will provide speed, efficiency, and dynamic data management. This convergence is being driven by initiatives like GS1 Sunrise 2027 and the rise of Digital Product Passports, which demand richer, more flexible data carriers. The technology that best aligns the needs of the physical item with the demands of the digital record will ultimately win, and in that race, the ability to read, write, and update data is a decisive advantage. |
|
References |
1. Heiskanen, S. (2025). *Pro Gradu: RFID and Barcode Technology Comparison*. Lappeenranta-Lahti University of Technology LUT. |
2. Pharmaceutical Commerce. (2026, May 27). How RFID-Enabled Mira Care Can Bolster Hospital Cold Storage Resilience. |
3. Dynamsoft. (n.d.). Code 39 - Barcode Types. |
4. BarcodeFYI. (2025). RFID et codes-barres : comp¨¦tition, coexistence et convergence. |
5. AIM Global. (2025). Connecting Innovation Across Borders: Bangkok Gatherings Discussed Identification Technology Breakthroughs. |
6. Universiti Tunku Abdul Rahman. (2015). *NFC Technology in Healthcare: A Study on Patient Identification*. |
7. Cognix. (n.d.). Code 39 Barcodes: How They Work. |
8. Research and Markets. (2026). *Automatic Identification & Data Capture Market Report 2026-2032*. |
9. AIM Global. (n.d.). *RFID: Read/Write - A White Paper*. |
10. Cold Chain Platform. (2026, June 2). Intelliguard and Accucold Introduce Integrated RFID-Enabled Mira Care Inventory Cabinet. |
11. Wikipedia. (2023). Code 39. |
12. TSC Auto ID. (2026). Barcodes vs. RFID: What's Right for Your Operation in 2027 |
