Decoding the Dot: A Deep Dive into Barcode Label Printer Electronics - Extended Section 1 | Subtitle: System Topology Overview - The Brain, the Brawn, and the Bus | Introductory Summary (Extended Section 1 Preview) | Before we walk through the entire printer, let us pause and look at the big picture. A barcode label printer is not one machine; it is five machines in one box. It is a power supply, a high-speed data shifter, a precision motor controller, a sensitive measurement instrument, and a communication hub - all working together within milliseconds. The secret to making all these parts cooperate is the system topology, which is simply the map of how the main processor talks to every other chip, sensor, and actuator. This chapter explains that map in plain language, using real-world examples from industry leaders. We will see how Texas Instruments designs its processor ecosystems, how STMicroelectronics handles real-time timing, how NXP manages power sequencing, how Infineon protects against faults, and how Microchip enables flexible expansion. We will also compare the philosophical differences between a 'centralized' design (one big CPU does everything) and a 'distributed' design (many small microcontrollers share the workload). By the end, you will understand why a printer that costs two hundred dollars at retail contains electronics that are more complex than a desktop computer from ten years ago, and you will appreciate the elegant engineering choices that make it all possible without crashing, overheating, or missing a single black dot on your shipping label. |
| Chapter 1: The Grand Architecture - A City of Chips | Imagine a busy city. At the center is the mayor's office - that is the main central processing unit, or CPU. The mayor does not deliver mail, fix roads, or put out fires. Instead, the mayor receives reports, makes decisions, and sends out orders. Around the mayor, there are specialized departments: the power plant (power supply), the fire department (thermal management), the transit authority (motor control), the census bureau (sensors), and the post office (communication ports). The roads that connect all these departments are the data buses - the electrical traces on the printed circuit board. In a barcode printer, this city must operate with zero traffic jams, because a delay of even one millisecond can cause a smeared label or a misprinted barcode that a supermarket scanner cannot read. | The first decision an engineer makes is: how powerful does the mayor need to beFor a simple desktop printer that prints only text and basic barcodes at low speed, an 8-bit microcontroller from the 1980s might still work. But for a modern industrial printer that prints complex graphics, QR codes, logos, and variable data at high speed, we need a 32-bit processor running at over 100 megahertz. The industry standard has settled on the ARM Cortex-M family, specifically the M4 and M7 cores, because they offer a good balance of processing power, power consumption, and cost. A typical printer uses a Cortex-M4 running at 120 to 180 MHz, with built-in floating-point math - which sounds fancy but simply means the processor can calculate energy corrections for each dot without slowing down. | Design Example: Texas Instruments Sitara AM335x | One of the most widely used processor families in mid-range industrial printers is the Texas Instruments Sitara AM335x series. This chip contains an ARM Cortex-A8 core running at up to 1 GHz, along with two programmable real-time units (PRUs) - tiny co-processors that act like dedicated traffic officers. In a barcode printer design from a major OEM (original equipment manufacturer), the main core handles the user interface, network communication, and file system, while one PRU is dedicated purely to generating the strobe signal for the printhead and the other PRU handles the step and direction pulses for the two stepper motors. This separation means the main core never gets interrupted, even if the network connection experiences a burst of traffic. The design example uses a 16-bit external memory interface to connect to 256 MB of DDR3 SDRAM, which stores the entire label image as a bitmap. The PRUs run their own tiny programs written in a simple assembly-like language, and they communicate with the main core through shared memory - a designated mailbox area where commands and status are exchanged. This architecture has been proven in thousands of shipping and logistics printers, and it demonstrates the principle of 'divide and conquer.' | Design Example: STMicroelectronics STM32H7 | On the lower-cost end, but still highly capable, the STMicroelectronics STM32H7 series is a favorite among printer designers. This chip uses a dual-core architecture: one Cortex-M7 at 480 MHz and one Cortex-M4 at 240 MHz. The M7 core, being faster, handles the print data processing - it takes the incoming label format (which might be in ZPL or EPL emulation) and renders it into a dot matrix in the internal SRAM. The M4 core acts as the 'peripheral manager,' reading the temperature sensor, controlling the LCD backlight, scanning the button matrix, and monitoring the paper-out sensor. The two cores communicate via a mailbox mechanism, and they share a common 2 MB of SRAM. A real product from a European printer manufacturer uses this exact chip and achieves a print speed of 10 inches per second - remarkably fast for a thermal transfer printer. The key to this speed is that the M7 core can dedicate 100% of its time to rendering, without ever pausing to check if the paper is jammed; the M4 core watches for jams and can trigger an emergency stop by sending an interrupt signal to the M7. |
| Chapter 2: The Data Highway - Buses and Protocols | The mayor cannot walk to every department; instead, there are roads of different sizes and speeds. In a printer, we have several types of buses. The widest and fastest is the parallel bus used to send image data to the printhead. This bus might be 8, 16, or even 32 bits wide, and it runs at speeds up to 50 MHz. But because the printhead itself is a long shift register, we usually serialize the data - meaning we send it one bit at a time over a single wire, but at a very high clock rate (up to 20 MHz). This serial peripheral interface (SPI) is the most common bus for printhead communication. For slower peripherals like the EEPROM memory that stores calibration settings, we use the I2C bus - which uses only two wires and runs at a leisurely 400 kHz. For motor drivers, we use either SPI (to set configuration registers) and dedicated step/direction pins (for real-time positioning). For the Ethernet port, we use a completely separate bus called MII (Media Independent Interface) that runs at 25 MHz and handles data packets independently of the main CPU. | The critical design rule is bus arbitration - ensuring that two devices do not try to talk at the same time. The processor has built-in direct memory access (DMA) controllers that act like autonomous mail carriers. Once the processor sets up a DMA transfer, the DMA controller moves data from memory to the printhead shift register without any further intervention from the CPU. This frees the processor to calculate the next line of dots while the current line is being printed. A typical print cycle uses three DMA channels simultaneously: one for shifting print data, one for reading sensor ADC values, and one for sending status updates over USB. This parallel operation is what makes high-speed printing possible. | Design Example: NXP LPC54000 Series with DMA Engine | NXP Semiconductors offers the LPC54000 series, which features a powerful DMA engine with 30 independent channels. In a design from a Japanese label printer company, 12 channels are used just for the printhead: one channel for each of the 12 strobe segments (since a 4-inch head is divided into 12 blocks of 72 dots each). The DMA channels are triggered by a single timer, so all 12 blocks shift data simultaneously. This design eliminates the delay of sequential shifting and reduces the total line time from 1.2 milliseconds to just 0.4 milliseconds. The DMA engine also handles the reading of the three ADC channels (printhead temperature, motor current, and supply voltage) at a rate of 10 kHz, storing the values in a circular buffer without any CPU overhead. The engineer who designed this system noted that the DMA feature alone reduced the required CPU clock speed from 200 MHz to 80 MHz, saving both cost and power. |
| Chapter 3: The Power-On Sequence - Not Just Flipping a Switch | When you plug in the printer, a carefully choreographed dance begins. The power supply comes up first, delivering 24 volts to the main bus. But the 24-volt rail does not go directly to the printhead or motors; instead, a power management integrated circuit (PMIC) waits for the voltage to stabilize. Once stable, the PMIC enables a 5-volt regulator, which powers the logic chips. After the 5-volt rail is stable, a 3.3-volt low-dropout regulator (LDO) turns on to power the CPU and memory. The CPU then releases its reset pin and starts executing boot code from an internal ROM. The boot code checks the external flash memory for a valid firmware image, verifies the checksum, and jumps to the main application. Only after the application starts does the CPU enable the 24-volt rail to the printhead and motor drivers - by setting a 'power enable' pin high. This sequencing prevents any scenario where the printhead receives power while the logic is still in an undefined state, which could cause all 832 dots to fire simultaneously and burn out the heating elements. | Design Example: Analog Devices MAX77620 PMIC | Many printer designs use the MAX77620 power management IC from Analog Devices (formerly Maxim). This chip integrates three buck regulators and six LDOs in a single 4x4 millimeter package. In a real product from a North American handheld printer manufacturer, the MAX77620 is configured to power up in the following order: first the 1.8V rail for the SDRAM, then the 1.2V core voltage for the CPU, then the 3.3V I/O rail, and finally the 5V rail for the USB transceiver. The PMIC has a built-in sequencer that can be programmed over I2C; the factory sets the delays between each rail. The design also uses the PMIC's 'power good' output pin, which connects to the CPU's reset input - the CPU remains in reset until all rails are within 5% of their nominal values. This is critical because if the CPU started running while the core voltage was too low, it could execute garbage instructions and corrupt the firmware memory. The handheld printer has a battery input between 7.2 and 12 volts, so the first stage is a boost converter that raises the voltage to a regulated 24V for the printhead - this is unusual because most desktop printers use an AC adapter. The PMIC handles this by prioritizing the boost converter startup before any other rails, ensuring that the printhead has a stable high-voltage supply before the logic attempts to shift data. |
| Chapter 4: Interrupts - The Art of Prioritizing Emergencies | In a printer, many events require immediate attention. The paper runs out - the sensor triggers an interrupt. The printhead overheats - the temperature comparator sends an interrupt. The user presses the feed button - that is also an interrupt. The CPU cannot poll (continuously check) all these inputs because it would waste millions of cycles. Instead, each event is connected to an interrupt pin on the CPU. When an event occurs, the CPU finishes its current instruction, saves its state, jumps to an interrupt service routine (ISR), handles the event, and then returns to what it was doing. The art of interrupt design is assigning priority levels. In a typical printer, the printhead strobe completion interrupt has the highest priority, because if we miss the end of a strobe, the next line will overlap with the previous one, causing a dark smudge. The motor step interrupt has the second highest priority, because the motor must step precisely at the right moment to maintain consistent dot spacing. The sensor interrupts have medium priority, and the button interrupts have the lowest priority because a human being will not notice a few milliseconds of delay. | Design Example: Infineon XMC4000 with Nested Vectored Interrupt Controller | Infineon's XMC4000 series uses the ARM standard Nested Vectored Interrupt Controller (NVIC) with up to 128 interrupt channels. In a German-made pharmaceutical label printer, the interrupt priority groups are set as follows: Group 0 (highest) contains the timer interrupt that marks the end of each dot line; Group 1 contains the quadrature encoder interrupt for the platen motor, which triggers every 0.5 mm of paper movement; Group 2 contains the over-temperature alarm from the printhead's analog comparator; Group 3 contains the USB endpoint interrupts for incoming data; and Group 4 (lowest) contains the button and LCD touch interrupts. The firmware engineers measured the worst-case interrupt latency - the time from the event happening to the CPU starting the ISR - and found it to be 2.2 microseconds for Group 0, which is well within the 5-microsecond requirement. They achieved this by placing the timer ISR and the encoder ISR in the CPU's tightly coupled memory (TCM), which is as fast as the CPU cache but without the unpredictability of cache misses. This real-time guarantee is essential because the printer uses a print speed of 14 inches per second, meaning each dot line is only 340 microseconds long - any delay longer than 10 microseconds would cause a visible banding defect. |
| Chapter 5: Memory Mapping - Where Everything Lives | The CPU sees the world through its address space - a range of numbers that corresponds to physical memory locations, peripheral registers, and external devices. The first part of the address space is reserved for internal flash memory, where the firmware resides. The second part is for internal SRAM, used for variables and stack. The third part is for external memory interfaces - the SDRAM frame buffer and the NOR flash for fonts. The fourth part is the peripheral memory map, where reading or writing to a specific address triggers a hardware operation - for example, writing a byte to address 0x4002_1000 might set the STROBE pin high. The fifth part is for configuration registers inside the CPU itself - things like clock dividers and interrupt priorities. The engineer's job is to partition this address space so that there are no conflicts and so that the most frequently accessed data is in the fastest memory. | Design Example: Microchip SAM E70 with External Bus Controller | Microchip's SAM E70 series includes a flexible external bus controller (EBC) that can interface with up to 4 external devices, each with its own chip select. A design from a Chinese barcode printer manufacturer uses this EBC to connect a 16 MB parallel NOR flash (for firmware backup), a 128 MB SDRAM (for label buffering), and a parallel LCD controller (for a 4.3-inch touchscreen). The memory map is carefully arranged: the NOR flash is mapped from address 0x6000_0000, the SDRAM from 0x7000_0000, and the LCD controller from 0x8000_0000. The CPU boots from internal flash, then copies the firmware from the external NOR flash to the internal SRAM if a firmware update is detected. The external SDRAM is used as a circular buffer - as the printhead consumes image data from the front, the DMA controller fills new data at the back. This circular buffer scheme allows the printer to store up to 8 full pages of labels, so even if the host computer pauses for a few seconds, the printer continues printing without interruption. The design uses 32-bit access to the SDRAM to achieve a bandwidth of 200 MB/s, which is more than enough for the 20 MB/s required by the printhead. |
| Chapter 6: Clock Distribution - The Heartbeat of the System | Every operation in a digital circuit is synchronized to a clock signal. The main clock comes from a crystal oscillator - typically a 25 MHz or 40 MHz fundamental mode quartz crystal, with two load capacitors of 18 pF each. The CPU multiplies this frequency using a phase-locked loop (PLL) to generate the core clock (120 MHz), the bus clock (60 MHz), and the peripheral clocks (various frequencies). But the printhead, motors, and communication ports have their own timing requirements. For example, the printhead shift register requires a clock between 10 and 20 MHz; the stepper motor driver needs a step pulse at a frequency that varies from 500 Hz to 50 kHz; the USB port requires a precise 48 MHz clock; and the Ethernet PHY requires a 25 MHz or 50 MHz clock depending on the speed. A modern printer uses a clock distribution chip that takes the main 25 MHz input and generates multiple output clocks, each with its own enable pin so that unused peripherals can be turned off to save power. | Design Example: Silicon Labs Si5351 Clock Generator | A prominent American industrial printer manufacturer uses the Si5351 programmable clock generator from Silicon Labs. This chip takes a 25 MHz reference and uses three internal PLLs to generate up to 8 independent output clocks. In their design, output 0 is set to 120 MHz for the CPU core, output 1 is set to 60 MHz for the SDRAM, output 2 is set to 20 MHz for the printhead shift clock, output 3 is set to 48 MHz for USB, output 4 is set to 25 MHz for Ethernet, output 5 is set to 16 MHz for the UART (which then divides down to 115200 baud), output 6 is set to 4 kHz for the buzzer, and output 7 is used as a variable clock for the stepper motor micro-stepping - the frequency changes dynamically as the motor speeds up and slows down. The Si5351 is controlled via I2C, and the CPU reconfigures the output frequencies on the fly. For example, when the printer enters power-save mode, the CPU commands the Si5351 to reduce the 120 MHz output to 12 MHz, cutting the core power consumption by 80%. The clock generator also has a spread-spectrum mode that slightly modulates the clock frequency to reduce electromagnetic interference - this is crucial for passing FCC and CE certification. The design note from their engineering team says that this single chip replaced four separate crystal oscillators and three clock buffers, saving board space and cost. |
| Chapter 7: The Reset Tree - Starting Over Gracefully | Even the best-designed systems sometimes need a reset. But a reset is not just a single event; it is a cascade. The main processor has a dedicated reset pin that, when pulled low, forces the CPU into a known state. But we also have reset controllers for the peripherals. For example, the USB controller has its own reset, the Ethernet MAC has its own, and the motor drivers each have an enable/reset pin. A well-designed printer uses a 'reset tree' - a single reset signal from the supervisory IC fans out to all devices, but each device has a slightly different timing. The CPU comes out of reset first, runs its bootloader, and then individually releases the resets of the peripherals in a controlled sequence. This prevents a situation where the motor driver tries to move the motor before the CPU has configured the current limits, which could cause a loud buzz or even damage the motor. | Design Example: On Semiconductor NCP302 Supervisory IC | A Taiwanese printer manufacturer uses the NCP302 reset supervisor from On Semiconductor. This chip monitors the 3.3V rail and asserts the reset pin for a minimum of 140 milliseconds after the voltage crosses the threshold. But their design adds an extra layer: the reset output goes not directly to the CPU, but to a small CPLD (complex programmable logic device) from Lattice Semiconductor. The CPLD generates four staggered reset signals: RESET_CPU goes high after 0 ms, RESET_PERIPH goes high after 50 ms, RESET_MOTOR goes high after 100 ms, and RESET_PRINTHEAD goes high after 200 ms. The CPLD also holds the printhead high-voltage enable pin low until RESET_PRINTHEAD is active, ensuring that the printhead power MOSFETs are never on during power-up. The CPLD is programmed with a state machine that also handles the emergency stop - if any fault condition (over-current, over-temperature, or motor stall) is detected, the CPLD can assert a global reset without waiting for the CPU, which might be hung. This hardware-level watchdog is a safety feature required by many industrial standards, including IEC 60950 for information technology equipment. |
| Chapter 8: Centralized vs. Distributed Control - A Design Philosophy | Now we come to one of the most important architectural decisions: should one powerful processor do everything, or should multiple smaller processors share the loadA centralized design is simpler - only one firmware image to develop and update, only one debug interface, and only one memory map to manage. However, as the printer gains more features - Ethernet, Wi-Fi, Bluetooth, touchscreen, multiple sensors, dual motors, and a high-speed printhead - the central CPU becomes overwhelmed. A distributed design uses a main CPU for the high-level application and several small microcontrollers, each handling a specific function. For example, a separate 8-bit microcontroller might manage the keyboard and display, another handles the motor speed profile, and yet another handles the thermal history of the printhead. The communication between these processors is usually over a simple serial bus like UART or I2C, with a defined protocol of commands and responses. | Design Example: Zebra Technologies' Distributed Architecture | Zebra Technologies, one of the world's largest barcode printer manufacturers, uses a distributed architecture in their high-end ZT600 series. The main processor is a Freescale (now NXP) i.MX6 Quad core running Linux - this handles the network stack, web server, file system, and user interface. Attached to this main processor are three separate Cortex-M0+ microcontrollers: one acts as a 'motor coprocessor' running a real-time motor control algorithm with a 10 kHz update rate; one acts as a 'printhead coprocessor' managing the strobe timing, thermal history, and energy correction; and the third acts as an 'I/O coprocessor' reading all sensors, debouncing buttons, and controlling LEDs. The three coprocessors communicate with the main CPU via a shared SPI bus, each with a unique chip select. The main CPU sends high-level commands like 'print this label at speed 6' or 'feed one label,' and the coprocessors handle the low-level details. This architecture has several advantages: the main CPU runs a complex operating system (Linux) that might have unpredictable delays due to process scheduling, but the coprocessors run bare-metal firmware with deterministic timing. The motor coprocessor, for example, generates its step pulses using a hardware timer, not software, so even if the main CPU freezes for 100 milliseconds, the motor continues stepping smoothly - the only consequence is that the label might have a blank gap, but the printer will not mechanically crash. | Design Example: Brother Industries' Centralized Approach | In contrast, Brother Industries - known for their desktop label printers - favors a centralized approach. Their popular QL series uses a single Renesas RX631 microcontroller running at 100 MHz. This chip has a built-in motor control timer unit that can generate the complex stepper motor waveforms without CPU intervention, and it has a separate serial interface unit that can shift printhead data using DMA. The firmware is written in a bare-metal environment (no operating system) and uses a cooperative scheduler - each task voluntarily yields control after completing its work. The scheduler runs a 'print task,' a 'sensor task,' a 'communication task,' and a 'UI task' in a round-robin fashion. The print task has the highest priority and runs every 500 microseconds; the sensor task runs every 10 milliseconds; the communication task runs whenever data is available; and the UI task runs 20 times per second. The benefit of this approach is that all state is shared in a single memory space - no need for inter-processor messaging, which can introduce latency. The drawback is that the firmware is more complex because the developer must ensure that no task ever blocks or delays the others. Brother achieves this by using hardware timers for all time-critical operations, so the CPU is only involved in setting up the timers and handling exceptions. This centralized design has proven extremely reliable, with millions of units shipped, and it keeps the bill of materials low because only one microcontroller is needed. |
| Chapter 9: Watchdog Timers - The Last Line of Defense | Even with perfect software, external events can cause a system to hang. A power glitch, an electrostatic discharge, or a rare software bug can make the CPU stop responding. The watchdog timer is a simple counter that counts down to zero; if it reaches zero, it resets the entire system. The firmware must periodically 'pet' the watchdog - write a specific value to a register - to reset the counter to its maximum value. If the firmware is stuck in an infinite loop or waiting for a response that never comes, the watchdog expires and forces a hardware reset. In a printer, the watchdog timeout is typically set to 1 or 2 seconds - long enough for normal operations but short enough to prevent a thermal runaway that could damage the printhead. The watchdog is usually an independent hardware block inside the CPU, but some designs use an external watchdog IC for added safety. | Design Example: Maxim MAX706 with Windowed Watchdog | A Korean printer manufacturer uses the MAX706 external watchdog IC in addition to the internal watchdog of the CPU. This IC has a 'windowed' feature: the watchdog must be petted within a specific time window - not too early and not too late. The window is from 1.0 seconds to 1.6 seconds after the last pet. If the firmware pets too early (faster than 1.0 second), the watchdog also resets the system. This guards against a failure mode where the firmware enters a tight loop that still pets the watchdog but never does useful work. The MAX706's reset output connects to both the CPU's reset pin and the enable pin of the printhead power MOSFET. When a watchdog reset occurs, the printhead power is immediately disconnected, and the CPU restarts. The design includes a diagnostic LED that blinks a specific pattern after a watchdog reset, so service technicians can identify the cause. The manufacturer reports that in field testing, the external watchdog caught three failures that the internal watchdog missed - all related to the I2C bus locking up, which prevented the internal watchdog from being petted but did not freeze the CPU entirely. |
| Chapter 10: The Bootloader - The First Software | When the CPU comes out of reset, the first thing it executes is the bootloader - a small program stored in a protected area of internal flash. The bootloader's job is to check if a firmware update is pending, verify the integrity of the main application, and then jump to it. If the main application is corrupted, the bootloader stays active and waits for a new firmware image over USB, Ethernet, or even Bluetooth. This is essential for remote updates in the field - a logistics company can update thousands of printers without sending a technician. The bootloader also sets up the initial clock configuration, because the main application might assume a certain clock speed. | Design Example: NXP MCUXpresso Secure Boot | NXP provides a secure bootloader as part of their MCUXpresso SDK. In a design from a European retail printer company, the bootloader uses a 256-bit AES key to decrypt the main firmware image stored in external flash. The key is stored in the CPU's one-time-programmable (OTP) memory, which cannot be read by software - only by a dedicated cryptographic block. On boot, the bootloader reads the encrypted image, decrypts it on the fly, calculates a SHA-256 hash, and compares it to the hash stored in the flash. If the hashes match, the bootloader copies the decrypted image to internal SRAM and executes it from there. The entire process takes about 300 milliseconds, which is acceptable because printers are not expected to start instantly. The secure boot prevents unauthorized firmware from running, which is important for printers used in government or financial applications - a malicious firmware could be designed to record the barcodes of classified documents or to skip the printing of certain labels. The bootloader also includes a recovery mode: if the power button is held during boot, the printer enters a USB mass storage mode, allowing a technician to drag-and-drop a new firmware file onto the printer's drive letter. |
| Chapter 11: Communication Between the Main Board and the Printhead Assembly | In many printer designs, the printhead is not soldered to the main PCB; it is connected by a flexible flat cable (FFC) that can be 15 to 30 centimeters long. This cable carries 24V power, ground, strobe signal, clock, data, latch, and several sensor lines. Because the printhead draws large currents (10-15 A peak), the cable must have low resistance - typically 40-gauge wire with multiple parallel contacts. The cable also acts as an antenna, so it must be carefully routed away from noise sources like the switching power supply. The main board includes a connector with gold-plated contacts and a locking mechanism to prevent the cable from working loose due to vibration. | Design Example: Molex 52745 FFC Connector | A design from a Japanese printer OEM uses the Molex 52745 series FFC connector, which has a pitch of 1.0 mm and 40 positions. The cable carries: 8 wires for 24V power (paralleled for low resistance), 8 wires for ground, 1 wire for strobe, 1 for clock, 1 for data, 1 for latch, 1 for printhead temperature sense, 1 for head ID resistor, and the remaining wires are spare. The connector includes a metal shield that connects to chassis ground, providing some EMI shielding. The main board also includes a ferrite bead array on the power lines near the connector, rated for 5 A per bead, to suppress high-frequency noise that could be radiated by the cable. The cable itself is specified with a characteristic impedance of 100 ohms, and the strobe, clock, and data lines have series termination resistors of 33 ohms at the driver end to match this impedance and prevent reflections. The designer measured the signal integrity at the printhead end and found that the clock signal had a rise time of 5 ns and a fall time of 6 ns, which is clean enough for reliable shifting at 20 MHz. |
| Chapter 12: Electromagnetic Compatibility Considerations from the Start | We cannot discuss system topology without mentioning EMC - electromagnetic compatibility. The switching power supply, the 20 MHz shift clock, the motor PWM, and the Ethernet PHY all generate conducted and radiated emissions. The design must pass both radiated and conducted emissions tests, as well as immunity tests like electrostatic discharge (ESD) and electrical fast transients (EFT). The topology of the PCB layout is the first line of defense. High-current loops must be kept small - the return current for the printhead should flow directly below the outgoing current on an adjacent layer. The motor drivers must have their own dedicated ground return to the main capacitor, separate from the logic ground. The Ethernet magnetics must be placed close to the connector to keep the high-voltage isolation area small. | Design Example: Cisco (former Linksys) Printer Design Guidelines | Cisco's printer division (now part of a separate entity) published an internal EMC design guide that many OEMs follow. In their design, the PCB is a 6-layer board with the following stack-up: top layer (components and high-current traces), layer 2 (solid ground plane), layer 3 (power distribution), layer 4 (signal routing), layer 5 (second ground plane), and bottom layer (low-speed signals and components). The two ground planes are connected by vias every 5 mm to create a low-impedance ground. The 24V power trace to the printhead is on layer 1, and its return path is on layer 2 directly underneath - this forms a tight loop with minimal inductance. The motor driver ICs are placed near the edge of the board, away from the analog sensor circuits. The crystal oscillator is surrounded by a guard ring of vias to prevent noise from coupling into the sensitive analog pins. The guide also recommends using a common-mode choke on the USB data lines and a ferrite bead on the USB power line. These measures, implemented from the start of the layout, reduced the need for post-production fixes, which can be expensive and time-consuming. |
| Chapter 13: Power Budgeting - Not All Watts Are Equal | An often-overlooked aspect of topology is power budgeting. The power supply must deliver peak power (15 A at 24V for the printhead, plus 2 A at 24V for motors, plus 2 A at 5V for logic) but the average power is much lower because the printhead is only on for a fraction of the time. A typical printhead duty cycle is 20%, so the average 24V current is about 3 A. The motor currents are also intermittent. The power supply can therefore be designed for a continuous rating of 80W with a peak capability of 360W for 2 milliseconds. This is achieved by using a power supply with a large output capacitor bank - typically 4,700 uF at 35V - that stores enough energy for the strobe pulse. The capacitor bank is charged between strobe pulses, and the charging time is determined by the supply's current limit. | Design Example: Mean Well GST120A24 Power Supply | Many printer manufacturers use off-the-shelf power supplies to reduce development time. The Mean Well GST120A24 is a popular choice - it provides 24V at 5A continuously (120W) and has a peak capability of 6.5A for 10 seconds. In a design from a Taiwanese industrial printer company, this supply feeds a 4,700 uF capacitor bank on the printer's main board. The 24V rail also goes to a 24V-to-5V DC-DC converter (TPS54360) rated at 3A, and the 5V rail powers a 3.3V LDO (MIC5209) rated at 500mA. The total typical power consumption is 45W (printing continuous black) and 15W (idle). The power supply has an efficiency of 88%, so it dissipates about 6W of heat at full load - this heat is vented through the printer's chassis. The design includes a power resistor (10 ohms, 10W) that discharges the capacitor bank when the printer is unplugged, ensuring that the high-voltage rail drops to a safe level within 2 seconds - this protects the printhead from a slow power-down that could leave the MOSFETs partially on. |
| Chapter 14: Thermal Management of the PCB Itself | The main PCB has several hot spots: the 24V-to-5V DC-DC converter, the 5V-to-3.3V LDO, the stepper motor driver ICs, and the CPU itself (which can dissipate up to 1.5W at full speed). These components must be placed with thermal considerations in mind. The DC-DC converter should be near the power input connector, with large copper pour areas for heat spreading. The motor drivers should have vias to an inner-layer ground plane that acts as a heat sink. The CPU should have a thermal pad on the bottom of the package, soldered to a copper area on the PCB that connects to multiple vias. | Design Example: TI TPS54335A Thermal Layout | In a reference design from Texas Instruments for a printer motherboard, the TPS54335A buck converter is laid out with a thermal pad connected to a 2x2 cm copper area on the top layer, stitched with 16 vias to the bottom layer copper area of the same size. The junction-to-ambient thermal resistance is measured at 28C/W, meaning that at 1.5W dissipation, the junction temperature rises 42C above ambient - safe for a maximum junction temperature of 125C. The design also includes a thermal sensor (TMP102) placed 5 mm from the CPU, which allows the firmware to throttle the CPU clock if the board temperature exceeds 70C. This throttling reduces the CPU's power dissipation from 1.2W to 0.5W, allowing the printer to continue printing at a reduced speed rather than shutting down completely. |
| Chapter 15: Circuit Protection - The Fuses and Polyfuses | A barcode printer operates in a rough environment - label adhesive can drip onto the PCB, operators can connect the wrong power adapter, and motors can stall. Over-current and over-voltage protection are essential. The 24V input has a fast-acting fuse (5A) and a transient voltage suppressor (TVS) diode rated at 30V. The motor drivers have individual current limits set by their sense resistors, but they also have a thermal shutdown feature. The printhead has a dedicated current monitor that compares the total current to a threshold; if the current exceeds 16A, a comparator triggers an interrupt and the CPU immediately pulls the strobe line low. | Design Example: Littelfuse 1812L Polyfuse | A design from a Scandinavian printer company uses a polyfuse (resettable fuse) from Littelfuse on the 24V rail to the motors. The 1812L series has a hold current of 2A and a trip current of 4A. If a motor stalls, the current rises to 3A, the polyfuse heats up and increases its resistance, limiting the current to a safe level. When the stall condition is removed (e.g., the user clears the jammed label), the polyfuse cools down and returns to its low-resistance state. This is much more convenient than a one-time fuse, which would require opening the printer to replace. The designer notes that the polyfuse has a slight voltage drop (about 0.3V at 2A), which is acceptable for the motors. The printhead, however, uses a one-time 15A fuse because the cost of a polyfuse capable of 15A is high, and the printhead is considered a consumable - if the fuse blows, it likely indicates a printhead failure anyway. |
| Chapter 16: Board-to-Board Connectors - The Spine of the System | In larger printers, the electronics are split across multiple PCBs: a main board, a power supply board, a front panel board (with buttons and display), and sometimes a separate motor driver board. These boards are connected by ribbon cables or board-to-board headers. The choice of connectors affects reliability, cost, and ease of assembly. For high-volume consumer printers, soldered ribbon cables are common. For industrial printers that may be repaired in the field, pin headers with locking latches are preferred. | Design Example: Samtec TLW Series Headers | A design from a US-based medical label printer uses Samtec TLW series headers - low-profile, surface-mount with a 1.27 mm pitch. The main board connects to the front panel board via a 10-pin header carrying 3.3V, ground, I2C, and two GPIO lines. The main board connects to the motor driver board via a 16-pin header carrying step, direction, enable, and fault signals for both motors, plus SPI for configuration. The connectors are specified for 100 insertions minimum, which is sufficient for the expected lifetime of a medical printer. The design uses a keying system - a missing pin on the connector - to prevent the cable from being plugged in backwards. This is a simple but crucial detail, because reversed power lines can destroy both boards instantly. |
| Chapter 17: The Role of the CPLD in System Glue | Even with a powerful CPU, there are tasks that require deterministic timing faster than software can achieve. A CPLD (complex programmable logic device) can act as 'system glue' - it can combine signals, generate timing pulses, and implement state machines that respond within nanoseconds. In a printer, a CPLD might handle the printhead strobe timing, because the strobe must be exactly the same duration for every dot line, regardless of what the CPU is doing. The CPU simply writes a 'fire' command to the CPLD, and the CPLD generates the strobe pulse of the precise width programmed in a register. | Design Example: Lattice MachXO2 CPLD | A design from an Australian printer manufacturer uses the Lattice MachXO2-1200 CPLD. This CPLD has 128 macrocells and operates at 3.3V. It is programmed to implement a printhead timing state machine with four states: idle, pre-charge, fire, and cool. The CPU writes a desired strobe width (in microseconds) to a 16-bit register in the CPLD's memory space. When the CPU writes a '1' to the fire register, the CPLD transitions to pre-charge (turns on the 24V pre-charge MOSFET), waits 2 microseconds for the voltage to settle, transitions to fire (activates the strobe), counts down the strobe width, transitions to cool (turns off strobe but keeps pre-charge on for 1 microsecond to bleed the inductive kick), and then returns to idle. The entire state machine runs on a 50 MHz internal clock, so its resolution is 20 nanoseconds. The CPU can continue shifting the next line's data while the CPLD handles the current line's firing. This offloading is critical because the CPU cannot afford to delay the strobe by even a few microseconds, which would change the dot energy. The CPLD also handles the emergency stop - if the over-temperature comparator trips, the CPLD immediately aborts any ongoing fire sequence, regardless of the CPU's commands. |
| Chapter 18: Isolation Between High-Voltage and Low-Voltage Domains | In a thermal printer, the 24V printhead supply and the 3.3V logic supply must coexist on the same PCB, but they must not interfere with each other. The isolation is achieved by physical separation - the high-voltage components (MOSFETs, capacitors, connectors) are placed on one side of the board, and the low-voltage logic (CPU, memory, sensors) on the other side. The traces between the two domains are routed through a narrow 'moat' where the ground planes are split, and only a few signals (the gate drive signals) cross the moat, via optocouplers or level shifters. In some designs, the level shifters are not needed if the gate drive signals are generated by the CPLD which runs at 5V - but many modern CPUs run at 3.3V, so a 3.3V-to-5V translator (such as the TXB0104) is used. | Design Example: Broadcom ACPL-P480 Optocoupler | A high-reliability printer used in aviation (for baggage tag labels) uses an optocoupler from Broadcom to isolate the strobe signal. The CPU generates a 3.3V strobe signal, which drives an LED inside the optocoupler. The LED's light activates a photodetector on the other side, which outputs a 5V strobe signal to the printhead driver. The optocoupler has a propagation delay of 50 nanoseconds and a common-mode transient immunity of 15 kV/microsecond - this means that even if a lightning strike induces a large voltage spike on the 24V rail, the spike cannot cross the optical barrier to affect the CPU. This design is overkill for most desktop printers, but it is required for medical and aviation applications where patient safety or flight safety is involved. |
| Chapter 19: The Debug Interface - A Window into the Brain | During development, engineers need to monitor the internal state of the CPU, set breakpoints, and step through code. The debug interface is usually a 10-pin or 20-pin connector that provides access to the CPU's JTAG or SWD (Serial Wire Debug) pins. In production, this connector might be omitted to save cost, but the pads are kept on the PCB so that a pogo-pin fixture can program the firmware during manufacturing. The debug interface also allows the bootloader to be programmed initially. | Design Example: ARM 10-pin Cortex Debug Connector | A design from a UK-based printer startup uses the standard 10-pin Cortex debug connector with the following pinout: pin 1 (VTREF, reference voltage from the target), pin 2 (SWDIO, data line), pin 3 (GND), pin 4 (SWCLK, clock line), pin 5 (GND), pin 6 (RESET, reset signal), and the remaining pins are either not connected or used for trace. The design includes a 100 kohm pull-up on SWDIO and a 100 kohm pull-down on RESET - this ensures that during power-up, the debug lines are in a known state and the CPU does not enter debug mode accidentally. The connector is placed near the edge of the board so that it can be accessed with the printer's cover closed during debugging, which is important because the printhead and motors only operate correctly when the cover is closed (due to safety interlock). The firmware enables the debug interface only during the first 5 seconds after boot; after that, it disables it to prevent unauthorized readout of the firmware. This is a security feature that prevents competitors from cloning the firmware. |
| Chapter 20: Firmware Update Mechanism - Field Upgrades | Once the printer is in the field, bugs will be found, and new features will be added. The firmware update mechanism must be robust and fail-safe. Most printers support update via USB mass storage - the user copies a .bin file to a USB drive, plugs it into the printer, and the printer's bootloader detects the file, verifies it, and flashes the internal memory. Some printers support over-the-air (OTA) updates via Wi-Fi or Ethernet, downloading the firmware from a cloud server. The update process must be atomic - if the power fails halfway through the update, the printer must still be able to boot from a backup firmware partition. | Design Example: DFU (Device Firmware Upgrade) over USB | A design from a South Korean consumer printer company uses the USB DFU class, which is standardized by the USB Implementers Forum. When the user holds the feed button while plugging in the USB cable, the printer enters DFU mode and appears as a DFU device to the host computer. The user runs a DFU utility that sends the new firmware image to the printer. The bootloader verifies the image's CRC and writes it to the main flash. If the CRC fails, the bootloader aborts and the old firmware remains intact. The design includes a dual-bank flash: a 512 KB main bank and a 512 KB backup bank. The bootloader always boots from the backup bank, which contains a minimal firmware that can perform updates. After a successful update, the bootloader copies the new firmware from the main bank to the backup bank, so that the backup bank is always a known-good version. This dual-bank strategy has been used in military and aerospace applications for decades, and it is now cost-effective enough for consumer printers. |
| Chapter 21: Power-Save Modes - Sleeping Without Losing State | A printer spends most of its life idle. To save energy and extend the lifetime of the printhead, the electronics must enter a low-power state. In this state, the CPU reduces its clock speed to 1 MHz or even stops the core entirely, keeping only the RTC and a few wake-up peripherals alive. The 24V rail to the printhead is turned off via a high-side switch. The motor drivers are put into a sleep mode that disables the H-bridges but retains the register settings. The USB peripheral is suspended, and the Ethernet PHY goes into a low-power idle state. The printer wakes up when the host computer sends data over USB, when the Ethernet receives a magic packet, when a button is pressed, or when a sensor detects a label being loaded. | Design Example: TI TPS65910 Power Management | A design from a German logistics printer uses the TPS65910 PMIC, which has a dedicated sleep mode. The CPU signals the PMIC to enter sleep by setting a GPIO high. The PMIC then turns off the 1.8V rail (SDRAM) and the 1.2V core rail, but keeps the 3.3V I/O rail active. The CPU enters a deep-sleep state with a wake-up timer set for 1 second. The CPU wakes up every second to check the sensors and the USB/Ethernet activity, then goes back to sleep. The average current in this state is 4 mA - compared to 350 mA in active mode, this is a 98% reduction. The PMIC can also be configured to wake up the system upon an external interrupt, such as a button press. The design includes a separate LDO for the RTC, powered by a coin cell battery, so that the real-time clock and the EEPROM retain their values even when the main power is removed - this is important for printers that are unplugged overnight but need to remember their configuration. |
| Chapter 22: Self-Healing Mechanisms - Automatic Recovery | A well-designed printer should attempt to recover from transient errors without user intervention. For example, if a label jam occurs, the printer should reverse the platen motor for a few steps and then try again. If the motor current sense indicates a stall, the driver should reduce the current and retry. If the printhead temperature exceeds the safe limit, the printer should reduce the print speed automatically. These self-healing mechanisms are implemented in the firmware, but they rely on the hardware topology providing the necessary feedback signals - current sense amplifiers, temperature sensors, and encoder inputs. | Design Example: HP (now independent) Printer Recovery Logic | A design from a former HP printer division uses a state machine in firmware that tracks the number of retries. When a paper jam is detected (sensor blocked for more than 200 ms), the printer stops the motors, reverses for 2 mm, then attempts to feed forward. If the jam persists after 5 retries, the printer declares a permanent jam and shuts down the motors, displaying an error code. The firmware logs the event in the EEPROM, along with the sensor values, the motor currents, and the temperature - this log can be retrieved by a technician for analysis. Similarly, if the printhead over-temperature protection triggers, the firmware reduces the strobe duty cycle by 5% and continues printing; if the temperature does not drop after 10 seconds, the printer stops and waits until the temperature falls below 50C. This automatic recovery reduces the number of service calls and improves the user experience. |
| Chapter 23: The Human Interface - Buttons, LEDs, and Buzzer Integration | The user interface is the part of the system that the operator sees and touches. It must be responsive and reliable. The buttons are connected to GPIOs with internal pull-up resistors. The LEDs are driven by simple transistor circuits. The buzzer is driven by a PWM output. The topology of the UI must be designed so that a button press does not cause a ground bounce that resets the system. This is achieved by using separate ground traces for the UI and by placing decoupling capacitors (0.1 uF) near each button. | Design Example: Diodes Incorporated APX803 Reset IC for UI | A design from a US-based retail printer uses the APX803 reset IC to monitor the 3.3V rail on the front panel board. If the voltage drops below 2.9V (due to a momentary short in the button matrix), the reset IC pulls the CPU's reset pin low, preventing a brown-out that could corrupt the flash memory. The front panel board also has a separate 5V regulator (a 78L05) for the backlight LEDs, which draw 100 mA each - this isolates the high-current LED switching from the sensitive analog sensor circuits on the main board. The buzzer driver is a simple push-pull pair of transistors (BC847/BC857) that can deliver 50 mA to the piezo element at 4 kHz. The design includes a jumper that disables the buzzer for quiet environments like libraries - a small but thoughtful feature. |
| Chapter 24: The Real-Time Operating System - To Use or Not to Use | Some printers use a lightweight RTOS (like FreeRTOS or Zephyr) to manage multiple tasks. Others use a simple super-loop (also called a 'foreground/background' system). The choice affects the topology only in terms of memory requirements - an RTOS needs a separate stack for each task, plus the kernel code. In a printer, the benefit of an RTOS is that it can prioritize the print task over the network task, ensuring real-time performance. The drawback is that the RTOS introduces some overhead and non-determinism in the worst-case interrupt latency. | Design Example: FreeRTOS on STM32F4 | A design from a Brazilian printer manufacturer uses FreeRTOS on an STM32F407. The tasks are: PrintTask (priority 5), SensorTask (priority 4), CommTask (priority 3), UITask (priority 2), and IdleTask (priority 0). The PrintTask runs every 500 microseconds when a print job is active, but it blocks on a semaphore that is given by the timer interrupt. This means the PrintTask does not consume CPU cycles when there is no printing. The CommTask handles incoming data over USB and Ethernet, parsing the label format and placing the rendered image into a queue. The UITask updates the LCD and reads buttons at a 10 Hz rate. The designers measured the maximum task switching time at 5 microseconds, which is acceptable. They also used the RTOS's software timers for debouncing buttons and for the watchdog petting. The firmware size with FreeRTOS is about 120 KB, compared to 80 KB for a super-loop version - the extra 40 KB is worth the improved maintainability and the ability to add features without breaking the timing. |
| Chapter 25: Multi-Core Communication - Message Passing | In a distributed architecture, the main CPU and the coprocessors must exchange data. This is typically done via message-passing over a shared memory or a serial link. The protocol includes a header with a message type, a length, and a payload, plus a checksum. The coprocessors have no file system or network stack; they simply respond to commands like 'set motor speed to 100 steps/s' or 'send temperature reading.' | Design Example: Texas Instruments PRU Messaging | In the Sitara AM335x design mentioned earlier, the main CPU and the PRUs communicate via a 4 KB shared RAM. The main CPU writes a command structure in the shared RAM and then sets a flag in a mailbox register. The PRU detects the flag, reads the command, executes it, and clears the flag. The PRU can also set its own flag to indicate that a command is complete or that an event (like a motor stall) has occurred. This message-passing is very efficient because it involves no interrupt overhead - the main CPU simply polls the flag at a 1 kHz rate. The designers chose polling instead of interrupts to avoid interrupt latency that could upset the USB timing. The shared RAM is implemented as a dual-port memory that both the CPU and PRU can access simultaneously without contention. |
| Chapter 26: Safety Interlocks - Protecting the Operator | A printer has moving parts and a hot printhead. Safety interlocks prevent the operator from being injured. The most common interlock is the cover-open switch - when the cover is opened, a micro-switch disconnects the 24V power to the motors and the printhead. This is a hardware interlock, not a software interlock, because software could fail. In some designs, the interlock is implemented with a relay that physically breaks the 24V circuit. The relay is normally open; the CPU can close it only when the cover is closed and all other safety conditions are met. | Design Example: Omron D3V-16 Micro-switch | A design from a Japanese manufacturer uses the Omron D3V-16 series micro-switch with a 16 A current rating. The switch is mounted on the printer's frame and is actuated by a cam on the cover hinge. When the cover is open, the switch breaks the 24V line to the printhead and motors, and also sends a signal to the CPU. The CPU detects this signal and displays 'Cover Open' on the LCD. The switch has a positive opening mechanism - even if the contacts weld together, a spring-loaded plastic actuator physically forces the contacts apart. This is a requirement for safety devices in many countries. The design also includes a second interlock on the ribbon rewind shaft - if the ribbon is jammed, a torque limiter disengages, and a sensor detects the loss of tension, triggering a shutdown. |
| Chapter 27: The AC Input Stage - Surge Protection | Before the power supply even starts, the AC input must be protected against surges from lightning or power grid switching. The typical protection is a metal-oxide varistor (MOV) across the line and neutral, followed by a gas discharge tube (GDT) for high-energy surges, and then a fuse. The MOV clamps the voltage to about 300V, the GDT handles the high current, and the fuse opens if the surge is too severe. | Design Example: Littelfuse TMOV20R Series | A design from a North American printer company uses the TMOV20R series, which is a thermally protected MOV - it contains an internal thermal fuse that opens if the MOV overheats from a prolonged overvoltage condition. This prevents the MOV from catching fire. The MOV is rated for 20 mm diameter, 275V AC, and 6.5 kA surge current. It is placed directly after the IEC inlet connector. After the MOV, there is a common-mode choke (2x 10 mH) and a differential-mode inductor (10 uH) to filter both common-mode and differential-mode noise. The AC input also has a 0.47 uF X2 capacitor across the line and neutral, and two 2.2 nF Y2 capacitors from line-to-ground and neutral-to-ground. These components form an EMI filter that attenuates frequencies above 150 kHz, helping the printer pass conducted emission tests. |
| Chapter 28: The Auxiliary Supply - Always-On 5V | Even in sleep mode, some parts of the printer need 5V - the USB transceiver, the Ethernet PHY, and the CPU's stand-by domain. This is called the auxiliary supply, and it is derived from the main 24V rail through a small buck converter that is always enabled. The auxiliary converter is designed for low quiescent current (less than 1 mA) because it is always on. | Design Example: TI TPS62130 Buck Converter | A design from a European printer manufacturer uses the TPS62130 for the auxiliary 5V supply. This converter operates from a 3V to 17V input (the 24V is divided down to 12V using a pre-regulator), and it delivers up to 3A. The quiescent current is only 17 uA, which is excellent for battery-powered operation. The converter is set to a switching frequency of 2.5 MHz, which allows the use of a small 1 uH inductor and a 4.7 uF output capacitor. The 5V aux rail powers the USB VBUS pin (through a 500 mA switch), the Ethernet PHY's core voltage, and the CPU's backup domain - the backup domain retains the RTC time and the EEPROM settings even when the main supply is off. The aux rail is diode-ORed with a 5V input from the USB host, so if the printer is unplugged but connected via USB, the USB host supplies the aux power, allowing the printer to wake up and print without the AC adapter. |
| Chapter 29: The Battery Backup - For Configurations | Some printers have an internal rechargeable battery that powers the real-time clock and the SRAM when the main power is off. This battery is typically a 3V lithium coin cell (CR2032) or a supercapacitor. The supercapacitor is preferred because it is rechargeable and does not need replacement, but it has a lower energy density. | Design Example: Seiko Instruments S-8201B Battery Protection | A design from a Chinese manufacturer uses the S-8201B battery protection IC to manage a 3.7V Li-ion battery that also powers the CPU during portable operation. The battery is charged via a linear charger (MCP73831) from the 5V rail. The battery voltage is monitored by an ADC; when it drops below 3.2V, the printer enters a low-power mode and saves the current label data to the EEPROM. The battery also provides the auxiliary 5V through a boost converter (TPS61070) that operates down to 0.9V - this allows the printer to use nearly all of the battery's capacity. The design includes a fuel-gauge IC (MAX17048) that estimates the remaining capacity using the battery's impedance tracking, providing a percentage display on the LCD. |
| Chapter 30: The Manufacturing Test Points - Designing for Production | A design that cannot be tested in production is a design that will fail in the field. The PCB must have test points - small pads or via holes - for every critical signal: power rails, clocks, reset, and communication lines. In the factory, a bed-of-nails fixture contacts these test points, and an automated tester checks for shorts, open circuits, and correct voltages. The test points also allow service technicians to measure signals with an oscilloscope. | Design Example: Test Point Layout Guidelines from JEDEC | A design from a Korean OEM follows JEDEC test point guidelines: each test point is a 1 mm diameter pad with a 0.3 mm plated through-hole, arranged in a grid with 2.54 mm pitch. The test points are placed on the bottom layer, so they do not interfere with component placement on the top layer. There are test points for the 24V rail, 5V rail, 3.3V rail, 1.8V rail, ground, reset, crystal oscillator output, and each of the SPI, I2C, and UART lines. The firmware includes a 'test mode' that is entered by a jumper on two test points; in test mode, the printer outputs a known pattern on the printhead and steps the motors in a deterministic sequence, allowing the production tester to verify the mechanical alignment as well as the electrical function. |
|
